2 How to Install Accessories Inside Your PC Workstation
Installing Mass Storage Devices
32 English
Connecting Devices
If you add an IDE Zip drive, hard disk drive, CD-ROM drive, CD-RW
drive, or tape drive, you need to connect it to power and data cables.
The data cables and connectors provided are shown below:
16-bit SCSI with five 68-pin SCSI connectors
Cable with two 40-pin connectors for
IDE Drives, such as CD-ROM Drives,
Zip Drives or Hard Disk Drives.
68-pin SCSI connectors
34-pin connector
40-pin connector
8-bit SCSI cable with two 50-pin
connectors for internal Ultra
narrow SCSI devices.
Cable with one connector for
3.5-inch Flexible Disk Drive
50-pin SCSI connectors
napa.bk : napa-ug2.fb4 Page 32 Monday, August 4, 1997 7:20 PM
