5. Remove four screws (callout 1).
Figure 2-96 Remove the laser/scanner (4 of 5)
1
6. Lift the laser/scanner up and out of the product.
Figure 2-97 Remove the laser/scanner (5 of 5)
ENWW Removal and replacement procedures 109
