Image formation process
Each of the following process function independently and must be coordinated with the other product
processes. Image formation consists of the following processes:
●
Latent-image formation block
◦
Step 1: primary charging
◦
Step 2: laser-beam exposure
●
Developing block
◦
Step 3: developing
●
Transfer block
◦
Step 4: transfer
◦
Step 5: separation
●
Fusing block
◦
Step 6: fusing
●
Drum cleaning block
◦
Step 7: drum cleaning
Figure 1-17 Image formation process
Drum cleaning
Developing
2. Laser-beam exposure
Fusing (Fixing)
6. Fusing (Fixing)
Delivery
7. Drum cleaning
3. Developing
1. Primary charging
Pickup
4. Transfer
5. Separation
Transfer
Latent image formation
: Media path
: Direction of drum rotation
: Block
: Step
ENWW Image-formation system 27
