In this example,
ports A7 and A8
have previously
been configured
as a trunk group.
----- --------- --------- ------- ------ ---------- ----- ----- ------
Port Status and Basic Configuration
Viewing Port Status and Configuring Port Parameters
ProCurve Switch 11-Sept-2007 8:46:35
==========================- CONSOLE - MANAGER MODE -============================
Status and Counters - Port Status
Intrusion MDI Flow Bcast
Port Type Alert Enabled Status Mode Mode Ctrl Limit
1 10/100TX No Yes Up 10FDx MDI off 0
2 10/100TX No Yes Up 10FDx MDI off 10
3 10/100TX No Yes Down 10FDx MDI off 0
4 10/100TX No Yes Down 10FDx MDI off 0
5 10/100TX No Yes Down 10FDx MDI off 0
6 10/100TX No Yes Down 10FDx MDIX off 0
7 10/100TX No Yes Down 10FDx MDI off 0
8 10/100TX No Yes Down 10FDx MDI off 0
9 10/100TX No Yes Down 10FDx MDI off 0
10 10/100TX No Yes Down 10FDx MDIX off 0
11 10/100TX No Yes Down 10FDx MDI off 0
Actions-> Back Intrusion log Help
Return to previous screen.
Use up/down arrow keys to scroll to other entries, left/right arrow keys to
change action selection, and <Enter> to execute action.
Figure 10-1. Example of the Port Status Screen
Using the Menu To Configure Ports.
Note The menu interface uses the same screen for configuring both individual ports
and port trunk groups. For information on port trunk groups, see Chapter 12,
“Port Trunking” .
1. From the Main Menu, Select:
2. Switch Configuration...
2. Port/Trunk Settings
10-7
