Monitoring and Analyzing Switch Operation
Status and Counters Data
CLI Access To Port and Trunk Group Statistics
To Display the Port Counter Summary Report. This command provides
an overview of port activity for all ports on the switch.
Syntax: show interfaces
To Display a Detailed Traffic Summary for Specific Ports. This com-
mand provides traffic details for the port(s) you specify.
Syntax: show interfaces [ethernet] < port-list >
To Reset the Port Counters for a Specific Port. This command resets
the counters for the specified ports to zero for the current session. (See the
“Note on Reset” on page B-10.)
Syntax: clear statistics < [ethernet] port-list >
Web Browser Access To View Port and Trunk Group Statistics
1. Click on the Status tab.
2. Click on Port Counters.
3. To reset the counters for a specific port, click anywhere in the row for
that port, then click on Refresh.
Viewing the Switch’s MAC Address Tables
Feature Default Menu CLI Web
viewing MAC addresses on all
ports on a specific VLAN
n/a page B-13 page B-15 —
viewing MAC addresses on a n/a page B-14 page B-15 —
specific port
searching for a MAC address n/a page B-14 page B-16 —
These features help you to view:
■ The MAC addresses that the switch has learned from network devices
attached to the switch
■ The port on which each MAC address was learned
B-12
