Configuring IP Addressing
IP Configuration
CLI: Configuring IP Address, Gateway, and Time-To-
Live (TTL)
IP Commands Used in This Section
show ip page 8-7
vlan <vlan-id> ip page 8-8
address
ip default-gateway page 8-11
ip ttl page 8-11
Viewing the Current IP Configuration. The following command displays
the IP addressing for each VLAN configured in the switch. If only the
DEFAULT_VLAN exists, then its IP configuration applies to all ports in the
switch. Where multiple VLANs are configured, the IP addressing is listed per
VLAN. The display includes switch-wide packet time-to-live, and (if config-
ured) the switch’s default gateway and Timep configuration.
Syntax: show ip
For example, in the factory-default configuration (no IP addressing assigned),
the switch’s IP addressing appears as:
Figure 8-2. Example of the Switch’s Default IP Addressing
With multiple VLANs and some other features configured, show ip provides
additional information:
8-7
