Configuring Port-Based and Client-Based Access Control (802.1X)
Displaying 802.1X Configuration, Statistics, and Counters
Table 10-3. Output for Determining Open VLAN Mode Status (Figure 10-7, Lower)
Status Indicator Meaning
Status Closed: Either no client is connected or the connected client has not received authorization through
802.1X authentication.
Open: An authorized 802.1X supplicant is connected to the port.
Current VLAN ID < vlan-id >: Lists the VID of the static, untagged VLAN to which the port currently belongs.
No PVID: The port is not an untagged member of any VLAN.
Current Port CoS Refer to the section describing RADIUS support for Identity-Driven
% Curr. Rate Limit
Management—IDM—in chapter 6, “RADIUS Authentication and Accounting”
Inbound
in this guide.
10-50

HP ProCurve 3500yl Series Specifications

General

Model	HP ProCurve 3500yl Series
Switching Capacity	176 Gbps
Layer	Layer 3
Input Voltage	100-240 VAC
PoE	Available on some models
Management	Web, CLI, SNMP
Routing Protocol	RIP, OSPF, BGP
Remote Management Protocol	Telnet
Features	VLAN
Power Consumption Operational	Varies by model
Memory	256 MB
Power Supply	Internal
Security Features	802.1X, RADIUS, TACACS+
Ports	24 or 48 x 10/100/1000Base-T ports
