HP ProLiant BL30p

Hardware Options Installation
8. Install the center plate in the main cage (1).
NOTE: Be sure the center plate is oriented as in the following figure. The pins must be
pointed down when being installed into the main cage.
9. Align the cover plate and slide into place on the main cage so that all four latches
lock into place (2).
10. Tighten the cover plate thumbscrew (3).
Figure 4-10: Installing the center plate and the cover
plate
4-10 HP ProLiant BL30p Server Blade Setup and Installation Guide
