Server Component Identification 59
Location LED Status
1 Power supply LED Off = No power or inadequate power supply
Green = Power supply is on and functioning
2 UID LED Blue = Activated
Off = Deactivated
Flashing = Remote inquiry
3 10/100/1000
NIC link LED
On = Link
Off = No Link
4 10/100/1000
NIC standby LED
On = Standby
Off = Activity
System Board Components
NOTE: PPM 1 is embedded onto the system board.
Item Description Item Description
1 Power supply connectors 15 64-bit 133-MHz PCI-X slot,
bus 6
