64 HP ProLiant ML350 Generation 4 Server Maintenance and Service Guide
Item LED Description Status
4 PPM 1 (embedded)
status
Off = PPM 1 functioning
Amber = PPM 1 failed
5 Processor 2 fan
status
Off = Processor fan is functioning
Amber = Fan is not installed or has failed
6 Processor 2 status Off = Processor 1 functioning
Amber = Processor 1 failed
7 PPM 2 status Off = PPM 2 functioning
Amber = PPM 2 failed
8 Temperature
threshold
Off = Normal
Amber = System temperature threshold
exceeded
9 Redundant system
fan status
Off = Fan is functioning
Amber = Redundant system fan has failed
10 Rear fan status Off = Processor fan is functioning
Amber = Fan is not installed or has failed
11 DIMM 4 status Off = DIMM 4 functioning
Amber = DIMM 4 failed
12 DIMM 3 status Off = DIMM 3 functioning
Amber = DIMM 3 failed
13 DIMM 2 status Off = DIMM 2 functioning
Amber = DIMM 2 failed
14 DIMM 1 status Off = DIMM 1 functioning
Amber = DIMM 1 failed
