78
Weight and physical dimensions
Table 14 lists physical properties for the SN6000 Fibre Channel Switch.
Electrical specifications
Table 15 lists electrical specifications for the SN6000 Fibre Channel Switch.
Environmental requirements
To ensure proper operation, the switch must not be subjected to environmental conditions beyond those for
which it was tested. The ranges specified in Table 16 identify the acceptable environment for both
operating and non-operating conditions.
Table 14 Switch physical dimensions
Property Value
Height 1U or 43.2 mm (1.70 in)
Width 432 mm (17 in)
Depth 500 mm (19.7 in)
Weight Dual power supply: 8.16 kg (18 lbs.)
Single power supply: 6.8 kg (15 lbs.)
Table 15 Electrical specifications
Specification Description
Operating voltage 100 to 240 VAC; 50 to 60 Hz
Power source loading (maximum) 1 A at 120 VAC/0.5 A at 240 VAC
Heat output (maximum) Dual power: 80 watts nominal; 90 watts typical maximum
Single power: 73 watts nominal; 83 watts typical maximum
Circuit protection Internally fused
Table 16 Environmental requirements
Condition Acceptable range during operation Acceptable range during
non-operation
Temperature 5° to 40°C (41° to 104°F) –20° to 70°C (–4° to 158°F)
Humidity 10% to 90%, non-condensing 10% to 95%, non-condensing
Altitude 3,048 m (0 to 10,000 feet) above sea
level
15,240 m (0 to 50,000 feet) above
sea level
Vibration (IEC 68-2-6) 5 to 500 Hz, 0.27g, 5 sweeps 2 to 200 Hz, 0.5g, 5 sweeps
Shock (IEC 68-2-7) 3.5g, 3ms, half sine, 20 repetitions 50g, 4216 mmps, 13msec, 3 axis
