Keyboard hook
Table 5-5 Keyboard hook description and part number
Description Spare part number
Keyboard hook L48424-001
Before removing the keyboard hook, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 22).
2. Remove the keyboard/top cover (see Keyboard/top cover on page 22).
Remove the keyboard hook:
1. Position the keyboard/top cover upside down with the front toward you.
2. Remove the Phillips M2.0 × 2.5 screw (1) that secures the keyboard hook to the top cover.
3. Remove the keyboard hook from the top cover (2).
Reverse this procedure to install the keyboard hook.
Component replacement procedures 29
