Battery
Table 5-6 Battery description and part number
Description Spare part number
Battery (2-cell, 37 Whr, 4.96 Ahr, polymer; includes cable) 824536-850
Before removing the battery, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 22).
2. Remove the keyboard/top cover (see Keyboard/top cover on page 22).
Remove the battery:
1. Disconnect the battery cable from the system board (1).
2. Remove the eight Phillips M2.0 × 2.5 screws (2) that secure the battery to the computer.
3. Remove the battery from the computer (3).
Reverse this procedure to install the battery.
30 Chapter 5 Removal and replacement procedures for authorized service provider parts
