5 Removal and replacement procedures for
authorized service provider parts
IMPORTANT: Components described in this chapter should only be accessed by an authorized service
provider. Accessing these parts can damage the computer or void the warranty.
NOTE: HP continually improves and changes product parts. For complete and current information on
supported parts for your computer, go to http://partsurfer.hp.com, select your country or region, and then
follow the on-screen instructions.
Component replacement procedures
There are as many as 50 screws that must be removed, replaced, and/or loosened when servicing the
computer. Make special note of each screw size and location during removal and replacement.
Preparation for disassembly
See Removal and replacement procedures preliminary requirements on page 17 for initial safety procedures.
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer
Keyboard/top cover
In this section, the rst table provides the main spare part number for the keyboards. The second table
provides the country codes.
Table
5-1 Keyboard/top cover and Rubber Foot Kit descriptions and part numbers
Description Spare part number
Keyboard/top cover
● For use in royal blue models L44441-xx1
● For use in diamond white models L44642-xx1
● For use in rose pink models L45168-xx1
Rubber Foot Kit
● For use in royal blue models L44455-001
● For use in diamond white models L44456-001
● For use in rose pink models L44457-001
22 Chapter 5 Removal and replacement procedures for authorized service provider parts
