66 CLI migration
Fibre topology
Port fibre topology values differ between the Command View CLI and the Command View AE CLI. Specify
the appropriate values based on your array type (XP48/XP512/XP128/XP1024/XP10000/XP12000).
See Table 23 if you are manually migrating from the Command View CLI to the Command View AE CLI.
Host mode values
Port host mode values differ between the Command View CLI and the Command View AE CLI. Specify the
appropriate values based on your array type (XP48/XP512/XP128/XP1024/XP10000/XP12000). See
the following table if you are manually migrating from the Command View CLI to the Command View AE
CLI.
11 D5 (A) 43 A5 (2A) 75 65 (4A) 107 2C (6A)
12 D4 (B) 44 A3 (2B) 76 63 (4B) 108 2B (6B)
13 D3 (C) 45 9F (2C) 77 5C (4C) 109 2A (6C)
14 D2 (D) 46 9E (2D) 78 5A (4D) 110 29 (6D)
15 D1 (E) 47 9D (2E) 79 59 (4E) 111 27 (6E)
16 CE (F) 48 9B (2F) 80 56 (4F) 112 26 (6F)
17 CD (10) 49 98 (30) 81 55 (50) 113 25 (70)
18 CC (11) 50 97 (31) 82 54 (51) 114 23 (71)
19 CB (12) 51 90 (32) 83 53 (52) 115 1F (72)
20 CA (13) 52 8F (33) 84 52 (53) 116 1E (73)
21 C9 (14) 53 88 (34) 85 51 (54) 117 1D (74)
22 C7 (15) 54 84 (35) 86 4E (55) 118 1B (75)
23 C6 (16) 55 82 (36) 87 4D (56) 119 18 (76)
24 C5 (17) 56 81 (37) 88 4C (57) 120 17 (77)
25 C3 (18) 57 80 (38) 89 4B (58) 121 10 (78)
26 BC (19) 58 7C (39) 90 4A (59) 122 0F (79)
27 BA (1A) 59 7A (3A) 91 49 (5A) 123 08 (7A)
28 B9 (1B) 60 79 (3B) 92 47 (5B) 124 04 (7B)
29 B6 (1C) 61 76 (3C) 93 46 (5C) 125 02 (7C)
30 B5 (1D) 62 75 (3D) 94 45 (5D) 126 01 (7D)
31 B4 (1E) 63 74 (3E) 95 43 (5E) 0 (**) -
32 B3 (1F) 64 73 (3F) 96 3C (5F)
Table 22 Fibre Addresses/Arbitrated Loop IDs (all array types)
Table 23 Port fibre topology values
Command View CLI
(Fibre Topology)
Command View AE CLI (Fibre Topology)
1 "Fabric (on), FC-AL"
2 (Default) "Fabric (off), FC-AL"
3 "Fabric (on), Point-to-Point"
4 "Fabric (off), Point-to-Point"
5"Not Fibre"
