Figure 23 HP XP7 AC power configuration diagram
Environmental specifications
The following table lists the environmental specifications of the HP XP7 storage system.
Table 27 HP XP7 environmental specifications
In StorageNot OperatingOperatingItem
-45 - 140-18 - 109.4 / -10 to 4360.8 - 80.9 /Temperature
-25 to 60-18 to 95 / -10 to 35
8
16 to 32(ºF / ºC)
5 to 958 to 9020 to 80Relative Humidity
(%)
2
84.2 / 2980.6 / 2778.8 / 26Max. Wet Bulb
(ºF / ºC)
68 / 2050 / 1050 / 10Temperature
Deviation
per hour)
(ºF / ºC)
Sine Vibration:5 to 10 Hz: 2.5 mm10 to 300 HzVibration
4.9 m/s
1
, 5 min.10 to 70 Hz: 4.9 m/s
1
0.49 m/s
1
to 10Hz: 0.25 mm
At the resonant frequency with
the highest displacement found
between 3 to 100 Hz
3
70 to 99 Hz: 0.05 mm
99 to 300 Hz: 9.8 m/s
1
Random Vibration:
0.147 m2/s3
Environmental specifications 81
