HP Xw6600 - Workstation - 2 GB RAM - Appendix A Appendix A-Connector Pins; Connector Pin Descriptions

A Appendix A—Connector pins
Connector pin descriptions
NOTE: Your workstation configuration might not include all connectors shown in this appendix.
Workstation keyboard connector Pin Signal
1
2
3
Data
Unused
Ground
4
5
6
+5 VDC
Clock
Unused
Workstation mouse connector Pin Signal
1
2
3
Data
Unused
Ground
4
5
6
+5 VDC
Clock
Unused
Workstation Ethernet connector Pin 10/100–MbSignal 1000–Mb
signal
1
2
3
4
(+) Transmit Data
(-) Transmit Data
(+) Receive Data
Unused
TX/RX
TX/RX
TX/RX
TX/RX
0
0
1
2
+
–
+
+
5
6
7
8
Unused
(-) Receive Data
Unused
Unused
RX/RX
TX/RX
TX/RX
TX/RX
2
1
3
3
–
–
+
–
ENWW Connector pin descriptions 145
