HP Z1 G2 Workstation
NOTE: The speed of the PCIe x16 link is determined by the processor and the graphics
card. If the processor or the graphics card only supports PCIe Gen2 speeds, the MXM PCIe
x16 link will run at Gen2 speeds.
●
Supports Intel HD Graphics 4400, 4600, or P4600 (depends on processor type)
NOTE: If an MXM graphics card is installed, Intel HD Graphics is disabled.
NOTE: Intel Core processors provide Intel HD Graphics 4400 or 4600; Intel Xeon processors
with model designations that end in "---5" provide Intel HD Graphics P4600.
NOTE: Intel HD graphics can drive up to 3 displays simultaneously. For example, it can drive the
internal display and a monitor attached to the external DisplayPort and a monitor attached to
the port on the optional Thunderbolt 2 module, if installed. Or it can drive 3 multistream displays
o the optional Thunderbolt 2 module, if installed; in this case the internal display will not be
active.
I/O technology
●
RAID congurations for SATA RAID levels 0, 1
●
External and internal USB 2.0 ports
●
External USB 3.0 ports; the lower port supplies USB battery charging
●
HP Low Power State technology enabled
●
Supports European Union ERP Lot 6 tier2 power limit of less than 0.5W in o mode
●
RJ-45 for LAN
●
DisplayPort (output/input)
●
Webcam
●
Digital microphone array
●
Headset and microphone
●
Line in and line out
●
Subwoofer
●
Optical S/PDIF output
●
SD 4.0 card reader
●
Thunderbolt 2 port(s) if optional Thunderbolt module installed
NOTE: MXM graphics supports 2 Thunderbolt 2 ports; Intel HD graphics supports 1
Thunderbolt 2 port.
Workstation specications 9
