HP Z24U G3 User Manual

10
18
Scrw_M2×2.8_U2419H
2
19
Rear_Cover_Z24u
1
20
Side_USB_Holder_Z24f_Z24_Z27
1
21
Side USB Board Z Series
1
22
Scrw_Tap_Pan_M3*0.6_NI
2
23
OSD_Holder_Z24f_Z24_Z27
1
24
OSD Holder Board Z Series
1
25
OSD_Key_Z24f_Z24_Z27
1
26
Scrw_Tap_Pan_M3*0.6_NI
2
27
Z_Logo_48mm_Pet_Black
1
28
Assy Hinge for Z24u G3
1
29
Scrw_Mec_Flat_M4L6_NI_STE
4
30
Pivot Cover for Z24u G3
1
31
Assy Stand Column for Z24u G3
1
32
Assy Base for Z24u G3
1
33
Driver Board Z24u G3
1
34
SCRW_MACHINE_M3*4
3
How to order parts
The HP authorized repair center can purchase the power board from HP.
Power board
Description
HP spare part
number
Manufacturer part number
POWER BD MH24WHC-BQDL(C)Z24u G3 LG/AUO D
M97967-001
755.A3905.0001
Capacitors and connectors are available for purchase from the following EU distributors:
 Digi-Key (RUBYCON ALU CAP): www.digikey.com
 CAPXON: www.capxongroup.com
Capacitors by distributor
Component description
Location
Component
distributor
Distributor part number
CAP EL 330U 35V M
10X12.5 ZLH RUBYCON
AC714,AC715,AC717,
AC718,AC719
RUBYCON
35ZLH330MEFCT8 10X12.5
CAP EL 330U 35V M
10*12.5 P5 CAPXON
CAPXON
ZH331M035G125ETABRZ
10*12.5

HP Z24U G3 Specifications

General

Screen Size	23.8 inches
Resolution	1920 x 1200
Panel Type	IPS
Aspect Ratio	16:10
Contrast Ratio	1000:1
Refresh Rate	60 Hz
Color Gamut	99% sRGB
Viewing Angle	178° horizontal, 178° vertical
Adjustability	Height, Tilt, Swivel, Pivot
Response Time	5ms
Ports	1 x DisplayPort 1.4, 1 x USB-C
VESA Mount	100 x 100 mm
Brightness	300 cd/m²
Pixel Pitch	0.2745 mm
