Mode button

PoE+ ports 1-24

Link/Act and Mode LEDs

SFP slots

10/100/1000BASE-T RJ-45 ports

Reset button

Network ports

• Auto-sensing 10/100/1000BASE-T ports.

All these ports have the “Auto-MDIX” feature, which means that you can use either straight-through or

crossover twisted-pair cables to connect any network devices to the switch.

• Power-over-Ethernet or PoE ports.

The 1920S PoE+ switches support the IEEE 802.3at standard, which allows IP telephones, wireless

LAN Access Points, and other appliances to receive power as well as data over existing LAN cabling.

For further information regarding PoE power, see the HPE Power over Ethernet (PoE/PoE+) Planning

and Implementation Guide, which is on the Hewlett Packard Enterprise Web site at www.hpe.com/

support/hpesc.

• PoE PD port (1920S 8G Switch only).

A network connection to the PoE PD port from a PoE PSE device powers on the switch.

• SFP slots for fiber or copper uplinks.

Using HPE SFPs, these products support optional network connectivity with the following speeds and

technologies:

NOTE:

Transceivers not on the 1920S approved list are used at your own risk and may void support and

warranty. Please see the HPE Warranty terms and conditions.

Transceiver Form-

Factor and Connector

Speed Technology Cabling SFP Connector

100 Mbps 100-FX Fiber (multimode) LC

1 Gbps 1000-T Copper (twisted-pair) RJ-45

1000-SX Fiber (multimode) LC

Table Continued

Network ports 9
