2. Verify the switch passes self test
Before mounting the switch, verify it is working properly by plugging it into a power source and confirming
that it passes self test.
Procedure
1. For the 1920S 24- and 48-port switches, connect the power cord supplied with the switch to the power
connector on the back of the switch, and then into a properly grounded electrical outlet.
For the 1920S 8-port switches, connect the AC/DC adapter’s power cord to the power connector on
the back of the switch, and then plug the AC/DC power adapter into a nearby properly grounded
electrical outlet.
HPE OfficeConnect 1920S 24- and 48-port switches
Connect the power cord to the switch and an AC power outlet.
HPE OfficeConnect 1920S 8G switch
Connect wall plug-in AC/DC power adapter to the switch and then to an AC power outlet.
1
2
HPE OfficeConnect 1920S 8G PPoE+ switch
Connect inline AC/DC power adapter to the switch and then to an AC power outlet.
16 2. Verify the switch passes self test

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HPE OfficeConnect 1920S Series and is the answer not in the manual?

HPE OfficeConnect 1920S Series Specifications

General IconGeneral
ModelHPE OfficeConnect 1920S Series
PoE+ SupportYes (on select models)
ManagementWeb-based GUI, SNMP
LayerLayer 2
MountingRack-mountable
Power SupplyInternal
Forwarding RateUp to 95.2 Mpps
Input Voltage100-240VAC
Power ConsumptionVaries by model
Operating Temperature0°C to 40°C (32°F to 104°F)
LatencyVaries by model
DimensionsVaries by model
WeightVaries by model
CertificationsCE, FCC, RoHS
Ports8, 24, or 48 ports
