To replace the component, reverse the removal procedure.
Replacing the two-bay LFF non-hot-plug drive backplane
About this task
Procedure
1. Back up all data.
2. If installed, remove the security bezel.
3. Power down the server.
4. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
5. Remove all non-hot-plug drives.
6. Do one of the following:
• Extend the server from the rack
• Remove the server from the rack
7. Remove the access panel.
8. Disconnect the cables from the system board.
Replacing the two-bay LFF non-hot-plug drive backplane 37
