To replace the components, reverse the removal procedure.
Replacing the RPS backplane
About this task
WARNING:
To reduce the risk of personal injury from hot surfaces, allow the drives and the internal system
components to cool before touching them.
CAUTION:
To prevent damage to electrical components, properly ground the server before beginning any
installation procedure. Improper grounding can cause ESD.
Procedure
1. If installed, remove the security bezel.
2. Power down the server.
3. Release the power cord from the strain relief clip.
4. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
5. Do one of the following:
• Extend the server from the rack
• Remove the server from the rack
6. Remove the access panel.
7. Remove the air baffle.
8. Remove the HPE Smart Storage Battery and holders.
9. Disconnect the RPS backplane cables.
70 Replacing the RPS backplane
