HPE ProLiant MicroServer Gen10 Plus v2 - Front Panel LED Power Fault Codes; Rear Panel Components

This LED only reflects the status of drives that are connected to the onboard SATA port.
This LED reflects the status of the onboard NIC ports and the optional iLO dedicated network port.
When these LEDs flash simultaneously, a power fault has occurred. For more information, see Front panel LED power fault codes.
If the health LED indicates a degraded or critical state, use iLO to review the system health status.
Facility power is not present, power cord is not attached, or power supply failure has occurred.
SubtopicsSubtopics
Front panel LED power fault codesFront panel LED power fault codes
Front panel LED power fault codesFront panel LED power fault codes
The following table provides a list of power fault codes, and the subsystems that are affected. Not all power faults are used by all servers.
SubsystemSubsystem LED behaviorLED behavior
System board 1 flash
Processor 2 flashes
Memory 3 flashes
Riser board PCIe slots 4 flashes
FlexibleLOM 5 flashes
Storage controller 6 flashes
System board PCIe slots 7 flashes
Power backplane 8 flashes
Storage backplane 9 flashes
Power supply 10 flashes
PCIe expansion cards installed in riser board 11 flashes
Chassis 12 flashes
GPU card 13 flashes
Rear panel componentsRear panel components
1
2
3
4
5
HPE ProLiant MicroServer Gen10 Plus v2 User Guide 8
