Removal and replacement procedures 28
To replace the component, reverse the removal procedure.
Drive 3 through 5 in the drive cage
CAUTION: To prevent improper cooling and thermal damage, do not operate the server
unless all bays are populated with either a component or a blank.
To remove the component:
1. Power down the server (on page 24).
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Remove the access panel (on page 24).
4. To disconnect power and SATA cables from drive 3 and the system board, do the following:
a. Disconnect SATA cable from drive 3.
b. Disconnect power cable from drive 3.
c. Disconnect SATA cable from SATA 3 connector on the system board.
