Removal and replacement procedures 35
6.
Remove the expansion board.
To replace the components, reverse the removal procedure.
Front USB module
CAUTION: To prevent damage to electrical components, take the appropriate anti-static
precautions before beginning any installation, removal, or replacement procedure. Improper
grounding can cause electrostatic discharge.
To remove the component:
1. Power down the server (on page 24).
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Remove the access panel (on page 24).
4. Remove all USB devices from the front panel.
5. Remove the tower bezel ("Tower bezel" on page 25).
6. Place the server on its side.
7. If drives are installed in the drive cage, remove the drive cage ("Drive 3 through 5 in the drive cage"
on page 28).
