Removal and replacement procedures 29
5.
Remove the drive cage from the chassis.
6. Remove the drive from the drive cage.
To replace the component, reverse the removal procedure.
Drive 6 in the drive enablement option
CAUTION: To prevent improper cooling and thermal damage, do not operate the server
unless all bays are populated with either a component or a blank.
To remove the component:
1. Power down the server (on page 24).
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Remove the access panel (on page 24).
