Item Description
12 Front USB 30 assembly connector
13 x1 SATA port 9
14 TPM connector
15 Fan connector 1 for the default and redundant PCI fans
16 Fan connector 2 for the redundant PCI fan
17 x1 SATA port 10
18 Controller backup power connectors (2)
19 microSD card slot
1
20 System maintenance switch
21 Energy pack connector
22 Internal USB 20 port
23 Slot 5 PCIe3 x8 (4, 1)
24 Serial port connector
25 Slot 4 PCIe3 x16 (16, 8, 4, 1)
26 Internal USB 30 port
27 Slot 3 PCIe3 x8 (8, 4, 1)
28 Slot 2 PCIe3 x8 (4, 1)
29 Slot 1 PCIe3 x16 (16, 8, 4, 1)
1
If the memory card connected to the microSD slot is not visible in Windows Device Manager, in the menu bar, click
View > Show hidden
device.
Component identification 13
