• Server in rack mode: Remove the server from the rack.
• Server in tower mode: Position the tower server for hardware configuration.
5. Remove the access panel.
6. Remove the front bezel.
7. Remove the PCI air baîš‚le.
8. Remove the system air baîš‚le.
9. Remove the default PCI fan.
10.
Install the redundant PCI fan:
a.
Insert the fan guard pins into the front chassis openings.
b.
Tighten the four T-15 screws.
Hardware options installation
96
