HPE SN2100M

Introduction to HPE StoreFabric M-Series SN2000M Spectrum™ Based Ethernet Switch
13
User Manual
*The system can support different interfaces and speed rates using QSFP to SFP adapters or
hybrid cables. For further information, see
“Breakout Cables and Adapters”.
1.3 Management Interfaces, PSUs and Fans
Table 4 lists the various management interfaces, PSUs and fans per system model.
1.4 Features
For a full feature list, please refer to the system’s product brief in HPE’s website: https://
www.hpe.com.
1.5 Certifications
The list of certifications (such as EMC, Safety and others) per system for different regions of the
world is located on the HPE website at:
https://www.hpe.com
1.6 Ordering Information
The following table lists ordering information for the available systems. Please pay attention to
the airflow direction when ordering your system. For more details, see
“Air Flow”.
SN2100M 64 (using QSFP to SFP breakout
cables)
16 (or 32 50GbE
interfaces when
using QSFP to
2xQSFP breakout
cables).
1.6Tb/s
Table 4 - Management Interfaces, PSUs and Fans
System Model USB MGT Console PSU Fan
SN2700M Rear Rear (2 ports) Rear 2 units 4 units
SN2410M/
SN2410bM
Rear Rear (2 ports) Rear 2 units 4 units
SN2100M Front (mini
USB)
Front (1 port) Front 2 units (non-
replaceable)
4 units (non-
replaceable)
Table 5 - Ordering Part Numbers (OPNs)
System
Model
HPE OPN Description
SN2700M Q2F21-63001 HPE StoreFabric M-Series SN2700M 100GbE 32QSFP28 Switch
Q6M26-63001 HPE StoreFabric M-Series SN2700M 100GbE 16QSFP28 Switch
Table 3 - Speed and Switching Capabilities
System Model 10/25GbE SFP28 Interfaces*
40/50/56/100GbE
QSFP28 Interfaces*
Max Throughput
