HPE SN2100M

Installation
17
User Manual
• 1 – DB9 to RJ-451 2m harness
2.5 19” Systems Mounting Options
By default, the SN2700M system is sold with the static rail kit described in Section 2.5.1. The
SN2410M/SN2410bM system is sold with the static rail kit described in Section 2.5.3. For the
telescopic rail kit installation instructions (can be used with SN2700M only), see Section 2.5.2.
The SN2100M system is sold without a rail kit. A designated rail kit can be purchased separately.
For installation instructions, see
Section 2.5.4.
2.5.1 Static Rail Kit for SN2700M
The following parts are included in the static rail kit (see Figure 7):
• 2x Rack mount rails (A)
• 2x Rack mount brackets (B)
• 2x Rack mount blades (C)
• 8x M6 Standard cage nuts¹ ² and 8x M6 Standard pan-head Phillips screws¹ (D)
• 4x Phillips100 DEG F.H TYPE-I ST.ST 6-32 X 1/4 screw with around patch (E)
¹ Other threads are available by special order: M5, 10-32, 12-24
² G-type cage-nut is available by special order.
A designated rail kit for the SN2100M systems can be purchased separately.
If anything is damaged or missing, contact your HPE sales representative.
At least two people are required to safely mount the system in the rack.
Table 6 - Installation Kit
Kit OPN Rack Size and Rack Depth Range
MTEF-KIT-A Short (17”-24”) or Standard (24”-34”)
