Step 4. Extract the loosened screws from Step 2 and dismount the system from the rack.
Step 5. Remove the rails and brackets from the chassis by unscrewing 8 screws.
2.5.2 Telescopic Rail Kit for SN2700M
There are two installation kit options:
• Standard depth systems should be mounted using the standard rail kit.
• Short depth systems can be mounted using either of the rail kits.
The following parts are included in the rail kit package (see Figure 14):
• 1x Right inner rail (A)
• 1x Left inner rail (B)
• 2x Outer rails (C)
• 2x Outer rails (D)
• 10x M6 Standard cage nuts¹ ² and 10x M6 Standard pan-head Phillips screws¹ (E)
• 2x Phillips100 DEG F.H TYPE-I ST.ST 6-32 X 1/4 screw with around patch (F)
¹ Other threads are available by special order: M5, 10-32, 12-24
² G-type cage-nut is available by special order.
The Telescopic rail kit is not included in the system’s package, and can be purchased
separately.
Table 7 - Installation Kit
Kit OPN Rack Size and Rack Depth Range
MTEF-KIT-B Short (17"-24" \ 43.1 to 61 cm)
MTEF-KIT-S Standard (24"-34" \ 61 to 86.3 cm)
The rails must be separated prior to the installation procedure. See Figure 15.
