Item Description Status
1 Interconnect link port LEDs
Solid green = Linked
Solid red = Error detected
1
.
O = No link
2 QSFP+ port LEDs
The four LEDs above each port correspond to the 10GbE or 8Gb FC
channels of the port. The LEDs display one of four modes:
Ethernet mode:
• Solid green = The port is configured as an Ethernet port.
• O = The port is not configured as an Ethernet port.
PID mode:
• Solid green = The port is configured as an uplink port.
• Solid amber = The port is configured as a stacking port.
• Solid purple = The port is configured as a mirrored port.
• Solid red = Error.
• Solid blue = Activated by OneView for port identification.
• O = The port is not configured.
Link/Activity mode:
• Solid green = 10Gb Ethernet link
• Flashing green = 10Gb Ethernet activity
• Solid amber = 8Gb FC link
• Flashing amber = 8Gb FC activity
• Solid purple = 40Gb Ethernet link
• Flashing purple = 40Gb Ethernet activity
• Solid Red = Error
• O = No link
Fibre Channel (FC) mode:
• Solid green = The port is configured as an FC port.
• O = The port is not configured as an FC port.
To switch between the LED modes, press the NEXT button.
3
NEXT button Selects the QSFP+ port LED mode.
4 Reset pin-hole Resets the module
Table Continued
Component and LED identification 43
