3. Using the screw supplied with the rack, connect the cable to the grounding rail.
Cabling the frame
WARNING: To reduce the risk of electric shock or injury due to high-current electrical energy, be sure that all power
is completely disconnected at the source before beginning any power connections to the power bus bars or power
bus box.
WARNING: Be sure that all circuit breakers are locked in the o position before connecting any power components.
Prerequisites
Download and review the HPE Synergy Cabling Guide from the Hewlett Packard Enterprise Information Library ( http://
www.hpe.com/info/synergy-docs).
84 Installation
