Component and LED identification
Information pull tabs
Pull tabs on the HPE Synergy frame front and rear provide system information.
Figure 1: Information pull tab locations
Item
Description
1 The front pull tab (top left) has the frame product ID, serial number, and the device bay numbering
for the frame front bays.
2 The rear pull tab (top left) has the bay numbering for the frame rear bays.
3 The serial label pull tab is on each compute module and provides the following information:
• Product serial number
• iLO information
• QR code that points to mobile-friendly documentation
Component and LED identification 13
