HPE Synergy 12000 Frame

Item Name Description
16 Reusable zip ties for power supplies (single-phase
frames only)
3
Reusable zip ties that help prevent single-
phase power cables from disconnecting from
the power connectors.
17 CAT6A cable or DAC cable or SFP+ DAC cable
1
,
3
CAT6A or DAC cable or SFP+ cable for
cabling frames, depending on the frame link
module ordered.
• 200 ft (6096 cm) cable—Used for
cabling two consecutive frames.
• 1000 ft (30480 cm) cable—Used for
cabling the top frame to the bottom
frame in a rack.
• 2100 ft (64008 cm) cable—Used for
cabling management links requiring long
runs to the top of the rack.
18
HPE Synergy Start Here Poster
3
The quick setup poster provides an overview
of the installation process.
19 Installation instructions for compute modules, options,
and interconnects
3
The printed installation instructions for HPE
Synergy components.
20 HPE Synergy 12000 Frame Rack Template
3
The printed template for locating the
positions of frames, rack rails, and cage nuts
in a rack.
1
Quantity as ordered
2
Quantity and type as ordered
3
Not shown
