HPE Synergy 12000 Frame

Item Name Description
1 HPE Synergy 12000 Frame
The frame for installing HPE Synergy
components.
2 Front panel
The front panel ports of the frame for KVM
connection.
3 Appliance module blank
A mandatory insert installed in any unused
appliance module bay.
4 Appliance module
1
A hardware appliance for embedded
management.
5 Compute module blank
A mandatory insert installed in any unused
compute module bay.
6 Full-height module
1
The full-height compute module.
7 Half-height module
1
The half-height compute module.
8 Power supply blank
A mandatory insert installed in any unused
power supply bay.
9 Hot-plug power supply
1
The power supply for the frame.
10 Fan
A fan used to cool the components installed
in the frame.
11 Frame link module
1
The frame link module auto-discovers
resources in the frame, has a redundant
option, and provides links for scaling of
frames.
12 Interconnect blank
A mandatory insert installed in any unused
interconnect bay.
13 Interconnect module
2
Any of several fabric or networking
components, such as switches or
interconnect link modules, that enable
networking communication.
14 Lift handles (optional)
3
The lift handles can be used to lift a frame
into or out of a rack.
15 Removable device bay shelves
3
The removable device bay shelves can be
used to partition the device bays for full or
half-height components.
Table Continued
