HPE Synergy 12000 Frame

Item Description Function
1 UID button Toggles the frame UID on or o.
2 Frame Health LED Indicates the highest severity health status of all components within the
frame.
• Solid green—Normal operation
• Flashing amber—Warning
• Flashing red—Critical error
To resolve critical errors and warnings, connect to HPE OneView or to the
HPE Synergy Console.
3 Laptop port Provides single laptop access to the frame link module using an RJ-45
Ethernet 100BASE-TX connection.
4 Monitor port Provides connectivity for a monitor or an active monitor port adapter to
access the HPE Synergy Console.
5 Reset button
Provides two functions:
• Resets the Active frame link module - momentary press.
• Factory resets both frame link modules - press and hold until UID LED
flashes blue.
NOTE: The reset button does not reset any other component in the
frame.
6 USB Provides a connection for supported USB devices such as a keyboard or
mouse for HPE Synergy Console use. To connect multiple devices, a USB
hub (not included) is required.
Appliance module LEDs and components
Appliance module LEDs and components are the same for both an HPE Synergy Composer (1st gen) and an HPE Synergy
Image Streamer. HPE Synergy Composer2 looks slightly dierent but has the same LED and components on the front
panel.
18 Component and LED identification
