Chapter 6 Function Introduction Shenzhen Hpmont Technology Co., Ltd
―94― HD20 Series Inverters User Manual
No. Name Description Range
【
factory setting
】
15: Reserved.
16: Output torque.
17: Output power.
18: DC bus voltage.
19: Potentiometer input voltage.
20: AI1 input voltage.
21: AI1 input voltage (after disposal).
22: AI2 input voltage.
23: AI2 input voltage (after disposal).
24－27: Reserved.
28: DI6 terminal pulse input frequency.
29: AO1 output.
30: AO2 output.
31: High-speed output pulse frequency.
32: Heatsink temperature.
33: Set the line speed
34: Reference line speed
35－36: Reserved.
37: Process PID reference.
38: Process PID feedback.
39: Process PID error.
40: Process PID integral value.
41: Process PID output.
42: External couting value.
43: Input terminal status.
• Bit0－Bit5 corresponding to DI1－DI6.
44: Output terminal status.
• Bit0－Bit2 corresponding to DO1, DO2, RLY1.
45: MODBUS communication status.
46: Actual length.
47: Total length.
48: Total time at power on (hour).
49: Total time at running (hour).
F18.14
Reserved
F18.15 Maximum line speed 0
－
65535
【
1000
】
F18.16
Line speed display accuracy
1－3【0】
0: Integer.
1: One decimal.
2: Two decimal.
3: Three decimal.
