hpmont HD20 Series - Group D: Display Parameters; Group D00 Status Display Parameters

Chapter 6 Function Introduction Shenzhen Hpmont Technology Co., Ltd
―48― HD20 Series Inverters User Manual
6.1 Group d: Display Parameters
Group d is status display parameters. The users can directly check the status parameters by
checking the function code of Group d.
6.1.1 Group d00 Status Display Parameters
No. Name Description Range
【
factory setting
】
d00.00 Series of the inverter
【
Actual value
】
Display the series of the inverter.
d00.01 Software version of the U1
【
Actual value
】
Display the software version of the U1.
d00.02 Software version of the I1
【
Actual value
】
Display the software version of the I1.
d00.03 Special software version of the U1
【
Actual value
】
Display the special software version of the U1.
d00.04 Special software version of the I1
【
Actual value
】
Display the special software version of the U1.
d00.05 Software version of the display panel
【
Actual value
】
Display the software version of the display panel.
d00.06 Customized series number
【
Actual value
】
Display the customized series number.
d00.07 Motor and control mode
【
Actual value
】
Display the present motor and the control mode.
Units: Display the present driving motor
• 0: Motor 1.
• 1: Motor 2.
Tens: Control mode
• 0: V/f contorl without PG.
• 1: Reserved.
• 2: Vector control without PG.
d00.08 Rated current of the inverter
【
Actual value
】
Display the rated current of the inverter.
d00.09 Reserved
