Shenzhen Hpmont Technology Co., Ltd Chapter 6 Function Introduction
HD20 Series Inverters User Manual ―49―
No. Name Description Range
factory setting
d00.10 Inverter status
Actual value
Display the inverter status, as shown in the following table:
Bit3 Bit2 Bit1 Bit0
Units
Zero speed running
0: In non-zero speed
runing
1: In zero speed running
Forward/reverse
0: Forward
1: Reverse
Run/stop
0: Stop
1: Run
Inverter fault
0: No fault
1: Fault
Tens
DC braking
0: Non-DC braking
status
1: In DC braking
Reserved
Bit1&Bit0:
Acceleration/deceleration/constant
00: Constant
11: Constant
01: Acceleration
10: Deceleration
Hundreds Reserved
Speed limiting
value
0: Not in the
limiting
1: In the limiting
Reserved
Parameter
auto-tuning
0: No auto-tuning
1: Auto-tuning
Thousands
Reserved Reserved
Current
limiting
0: In
1: Not in
Stall overvoltage
0: In
1: Not in
d00.11 Master setting frequency source
Actual value
Display the master setting frequency source, see parameter F00.10.
d00.12 Master setting frequency
Actual value
Display the master setting frequency.
d00.13 Auxiliary setting frequency
Actual value
Display the auxiliary setting frequency.
d00.14 Setting frequency
Actual value
Display the target setting frequency.
d00.15 Reference frequency (after acceleration/deceleration)
Actual value
Display the reference frequency for the change of the acceleration/deceleration.
d00.16 Output frequency
Actual value
Display the output frequency.
d00.17 Setting RPM
Actual value
Display the setting RPM.
d00.18 Running RPM
Actual value
Display the running RPM.
d00.19 Reserved
Display output voltage.
Display output current.
d00.23 Output torque
Actual value
Display output torque which is the relative percentage of the motor rated torque.
