Chapter 2 Product Information Shenzhen Hpmont Technology Co., Ltd
―8― HD20 Series Inverters User Manual
Item Specification
Environment
Operation temperature
-10－+40℃, air temperature fluctuation is less than 0.5℃/min
The derating value of the output current of the inverter shall be 2%
for each degree centigrade above 40℃. Max. allowed temperature
is 50℃
Storage temperature -40－+70℃
Location for use
Indoor, preventing from direct sunlight, no dust, corrosive,
flammable gases, oil mist, water vaper, dripping or salt etc.
Altitude Less than 1000 meters, otherwise should be derating use
Humidity Less than 95%RH, non-condensing
Oscillation Less than 5.9m/s
2
(0.6g)
Options
Bus communication
PROFIBUS option (HDFB-PROFIBUS-DP)
DeviceNet option (HDFB-DeviceNet)
CAN option (HDFB-CAN)
About display panel
Status display panel (HD-LED-L)
LCD display panel (HD-LCD)
Mounting base to panel (HD-KMB)
1 meter extension cable to panel (HD-CAB-1M)
2 meter extension cable to panel (HD-CAB-2M)
3 meter extension cable to panel (HD-CAB-3M)
6 meter extension cable to panel (HD-CAB-6M)
2.4 Ratings
Model
Rated capacity
(kVA)
Rated input
current (A)
Rated output
current (A)
Motor power (kW)
Single-phase power supply: 200
240V, 50/60Hz
HD20-2S0P2G 0.6 4.3 1.7 0.25
HD20-2S0P4G 1.0 5.8 2.5 0.4
Single/three-phase power supply: 200
240V, 50/60Hz
HD20-2D0P7G 1.5 10.5 4.0 0.75
HD20-2D1P5G 2.8 18.5 7.5 1.5
HD20-2D2P2G 3.8 24.1 10.0 2.2
Three-phase power supply: 380
460V, 50/60Hz
HD20-4T0P4G 1.0 1.8 1.4 0.4
HD20-4T0P7G 1.5 3.4 2.3 0.75
HD20-4T1P5G 2.5 5.2 3.8 1.5
HD20-4T2P2G 3.4 7.3 5.1 2.2
HD20-4T3P0G 4.8 9.5 7.2 3.0
HD20-4T4P0G 5.9 11.9 9.0 4.0
HD20-4T5P5G 8.5 15 13 5.5
To Next Page
