hpmont HD20 Series User Manual

Shenzhen Hpmont Technology Co., Ltd Chapter 3 Mechanical Installation
HD20 Series Inverters User Manual ―15―
3.6 Plastic Cover Dismantle
Remove the terminal cover in accordance with Figure 3-6 and Figure 3-7 due to different models.
Figure 3-6 Dismantle the terminal cover figure 1
Figure 3-7 Dismantle the terminal cover figure 2
Extrude the hook, and take off the terminal cover
The removing proceese:
Extrude the hooks at both side together, and take off the terminal cover
The removing proceese:
3
