9.2 Braking Resistor Selection
Table 9-1 Recommendation for the braking resistor
Model
Adaptive
motor
Braking resistor
resistance
Braking resistor
power
Braking unit
HD20-2S0P2G 0.25 kW 250－350 Ω 50 W Built-in
HD20-2S0P4G 0.4 kW 200－300 Ω 50 W Built-in
HD20-2D0P7G 0.75 kW 150－250 Ω 80 W Built-in
HD20-2D1P5G 1.5 kW 100－150 Ω 100 W Built-in
HD20-2D2P2G 2.2 kW 60－100 Ω 200 W Built-in
HD20-4T0P4G 0.4 kW 300－400 Ω 80 W Built-in
HD20-4T0P7G 0.75 kW 250－350 Ω 100 W Built-in
HD20-4T1P5G 1.5 kW 200－300 Ω 200 W Built-in
HD20-4T2P2G 2.2 kW 150－250 Ω 250 W Built-in
HD20-4T3P0G 3.0 kW 100－150 Ω 300 W Built-in
HD20-4T4P0G 4.0 kW 100－150 Ω 300 W Built-in
HD20-4T5P5G 5.5 kW 80－100 Ω 500 W Built-in
