hpmont HD20 Series User Manual

Shenzhen Hpmont Technology Co., Ltd Chapter 6 Function Introduction
HD20 Series Inverters User Manual ―89―
6.2.17 Group F16 Analogue I/O Terminal Parameters
No. Name Description Range
【
factory setting
】
F16.00 Display panel with potentiometer function selection 0
－
7
【
0
】
F16.01
Analogue input AI1 function selection
0－7【2】
F16.02 Analogue input AI2 function selection 0
－
7
【
5
】
0: Reserved.
1: Upper limit frequency setting.
• When F00.07 = 1 (upper limit frequency setting source is set by analogue input), the upper limit
frequency will be set by the input voltage value corresponding to the analogue source which
selects this function.
2: Frequency setting.
• When F00.10 = 3 (frequency setting source is set by analogue input), the setting frequency will
be set by the input voltage value corresponding to the analogue source which selects this
function.
3: Auxiliary frequency reference.
• When F19.00 = 4 (auxiliary frequency reference is set by AI analogue), the auxiliary frequency
will be set by the input voltage value corresponding to the analogue source which selects this
function.
4: Process PID reference.
• When F04.01 = 1 (process PID reference is set by AI analogue), the process PID reference will
be set by the input voltage value corresponding to the analogue source which selects this
function.
5: Process PID feedback.
• When F04.02 = 0 (AI analogue inputs process PID feedback), the process PID feedback will be
set by the input voltage value corresponding to the analogue source which selects this function.
6: Process PID regulating upper limit.
• When F04.11 = 1 (upper limit value of the PID regulator is set by AI analogue), the process PID
regulating upper limit will be set by the input voltage value corresponding to the analogue
source which selects this function.
7: Process PID regulating lower limit.
• When F04.12 = 1 (lower limit value of the PID regulator is set by AI analogue), the process PID
regulating lower limit will be set by the input voltage value corresponding to the analogue
source which selects this function.
F16.03 Reserved
F16.04
Reserved
6
