Chapter 6 Function Introduction Shenzhen Hpmont Technology Co., Ltd
―50― HD20 Series Inverters User Manual
No. Name Description Range
factory setting
d00.24 Output power
Actual value
Display output power which is the relative percentage of the motor rated power.
d00.25 DC bus voltage
Actual value
Display DC bus voltage.
d00.26 Potentiometer input voltage of the display panel
Actual value
Display potentiometer input voltage of the display panel.
d00.27 AI1 input voltage
Actual value
Display AI1 input voltage.
d00.28 AI1 input voltage (after disposal)
Actual value
Display A1 input voltage which is disposed by the gain, bias, analogue curve and filter.
d00.29 AI2 input voltage
Actual value
Display AI2 input voltage. When AI2 selects current input, the corresponding relations are: 0V
corresponds to 0mA and 10.00V corresponds to 20mA.
d00.30 AI2 input voltage (after disposal)
Actual value
Display A2 input voltage which is disposed by the gain, bias, analogue curve and filter.
d00.31 Reserved
d00.33 Reserved
d00.35 DI6 terminal pulse input frequency
Actual value
Display DI6 terminal pulse input frequency(Hz).
d00.36 AO1 output
Actual value
Display AO1 output. When AO1 selects current output, the corresponding relations are: 0V
corresponds to 0mA and 10.00V corresponds to 20mA.
d00.37 AO2 output
Actual value
Display AO2 output. When AO2 selects current output, the corresponding relations are: 0V
corresponds to 0mA and 10.00V corresponds to 20mA.
d00.38 High-speed output pulse frequency
Actual value
Display high-speed output pulse frequency(Hz).
d00.39 Heatsink temperature
Actual value
Display heatsink temperature.
d00.40 Setting line speed
Actual value
Display the setting line speed.
d00.41 Reference line speed
Actual value
Display the reference line speed.
d00.42 Reserved
d00.44 Process PID reference
Actual value
Display process PID reference relative to full scale (10.00V) percentage.
d00.45 Process PID feedback
Actual value
Display process PID feedback relative to full scale (10.00V) percentage.
d00.46 Process PID tolerance
Actual value
Display process PID tolerance relative to full scale (10.00V) percentage.
