hpmont HD20 Series User Manual

Shenzhen Hpmont Technology Co., Ltd Appendix B Communication Protocol
HD20 Series Inverters User Manual －165－
5. F00.11=2, give the reverse operation command to the address 2 of Slave
Address Code Register address Register content Checksum
0x02 0x06 0x32 0x00 0x10 0x03 0xCA 0x80
Corresponding answer frame:
Address Code Register address Register content Checksum
0x02 0x06 0x32 0x00 0x10 0x03 0xCA 0x80
6. F00.11=2, give the deceleration stop command to the address 2 of Slave
Address Code Register address Register content Checksum
0x02 0x41 0x32 0x00 0x10 0x04 0x3F 0x4D
Corresponding answer frame:
Address Code Register address Register content Checksum
0x02 0x41 0x32 0x00 0x10 0x04 0x3F 0x4D
7. F00.11=2, give the emergency stop command to the address 2 of Slave
Address Code Register address Register content Checksum
0x02 0x41 0x32 0x00 0x10 0x08 0x3F 0x48
Corresponding answer frame:
Address Code Register address Register content Checksum
0x02 0x41 0x32 0x00 0x10 0x08 0x3F 0x48
8. F00.11=2, give the coast to stop command to the address 2 of Slave
Address Code Register address Register content Checksum
0x02 0x41 0x32 0x00 0x10 0x10 0x3F 0x42
Corresponding answer frame:
Address Code Register address Register content Checksum
0x02 0x41 0x32 0x00 0x10 0x10 0x3F 0x42
9. External fault stop control of Slave 2 via communication (E0024 fault)
Address Parameter Register address Register content Checksum
0x02 0x41 0x32 0x00 0x10 0x20 0x3F 0x56
Corresponding answer frame:
Address Code Register address Register content Checksum
0x02 0x41 0x32 0x00 0x10 0x20 0x3F 0x56
B
