HD5L Series Controller User Manual －113－
Code Name Range Default Unit Attributes Setting
F00.06 M-key function
0: Disable
1: UP/DN swtich
0 1 ○
F00.07 Speed setting of panel 0.000m/s－F00.02 1.500m/s
0.001
m/s
○
F00.08 Run direction
0: The same as run
command.
1: Opposite to run command.
0 1 ×
Group F01 Protection of Parameters (on pages 61
－
62)
F01.00 User password 00000－65535 00000 1 ○
F01.01 Menu mode
0: Full menu mode
1: Checking menu mode.
Only different from factory
setting parameters can be
displayed.
0 1 ○
F01.02 Parameter initialization
0: No operation
1: Restore to factory settings
2: Parameter download
3: Clear fault information
0 1 ×
F01.03
Panel EEPROM
parameter initialization
0:No operation
1: Parameters upload
0 1 ○
Group F02 Start & Stop Parameters (on pages 62
－
63)
F02.00 Start delay time 0.000－4.999s 0.000s 0.001s ×
F02.01 Brake open delay time 0.000－4.999s 0.000s 0.001s ×
F02.02
Retention time of start
zero-speed
0.000－4.999s 0.500s 0.001s ×
F02.03 Start speed 0.000－0.400m/s 0.000m/s
0.001
m/s
×
F02.04
Retention time of start
speed
0.000－4.999s 0.000s 0.001s ×
F02.05 Brake close delay time 0.000－4.999s 0.000s 0.001s ×
F02.06
Retention time of stop
zero-speed
0.000－4.999s 0.000s 0.001s ×
F02.07
Contator close delay
time
0.000－4.999s 0.000s 0.001s ×
F02.08 Start ramp time
0.000－2.000s
0.000: No ramp
0.000s 0.001s ×
F02.09 Reserved
Group F03 Acceleration/Deceleration Parameters (on pages 63
－
64)
F03.00 Acceleration speed 0.020－9.999m/s
2
0.700m/s
2
0.001
m/s
2
×
F03.01 Start Acc jerk 0.020－9.999m/s
3
0.350m/s
3
0.001
m/s
3
×
F03.02 End Acc jerk 0.020－9.999m/s
3
0.600m/s
3
0.001
m/s
3
×
F03.03 Deceleration speed 0.020－9.999m/s
2
0.700m/s
2
0.001
×
A
