Appendix B Communication Protocol Shenzhen Hpmont Technology Co., Ltd
―136― HD5L Series Controller User Manual
Characteristics (Bit) Value Definition
Bit5－Bit3
001B To display length 1
010B To display length 2
011B To display length 3
100B To display length 4
101B To display length 5
Reserved
Bit7－Bit6
00B Actual parameters, unchangeable
01B Changeable
10B Unchangeable in running state
11B Set by factory, cannot be modified
Bit12－Bit8
00000B Without char
00001B Unit is Hz
00010B Unit is A
00011B Unit is V
00100B Unit is rpm
00101B Unit is %
00110B Unit is s
00111B Unit is Ω
01000B Unit is ms
01001B Unit is kHz
01010B Unit is k kW.h
01011B Unit is kW.h
01100B Unit is mH
01101B Unit is m
01110B Unit is cm
01111B Unit is kΩ
10000B Unit is Hz/s
10001B Unit is h
10010B Unit is kW
10011B Unit is℃
10100B Unit is s/times
10101B Unit is m/s
10110B Unit is m/s
2
10111B Unit is m/s
3
11000B Unit is mm
11001B Unit is m/min
11010B Unit is kg/m
3
11011B Unit is N
Others reserved
