6 Operation and regulation
78
HSD S.p.A. © - 0106h03a.fm100713
6.8.8 Electrospindle states and corresponding outputs from
inductive sensors
ES327 and ES330 “air”
ES330 “liquid”
The sensor “ON” condition corresponds to an output equal to the power supply
voltage. The “OFF” condition corresponds to a 0 V output..
STATE S1 S2
Collet open
(tool holder cone ejected)
OFF ON
Tool holder cone
coupled
ON OFF
Collet closed but
with no tool holder cone
OFF OFF
The electrospindle shaft can only rotate in the "tool holder cone coupled" state;
if S1 output changes to “OFF”, stop the rotation of the electrospindle shaft.
STATE S2 S3 S4 Pulse counter Sensor
Collet open
(tool holder cone ejected)
ON OFF OFF STILL
Tool holder cone
coupled
OFF OFF ON
IDLE or
STARTED UP*
*
Depending on the operating status of the electrospindle.
Collet closed but
with no tool holder cone
OFF ON OFF STILL
The electrospindle shaft can only rotate in the "tool holder cone coupled" state;
if S4 output changes to “OFF”, stop the rotation of the electrospindle shaft.
